搭載 Xilinx Zynq UltraScale+ RFSoC 晶片，專為雷達與通訊系統量身打造。
整合了多通道的高速 ADC 與 DAC，大幅減少系統布線複雜度與延遲。
Break the Boundaries: The Perfect Fusion of High-Speed Computing and RF Sampling.
•PL
•8* ADC FMC2 Connector (14 bit, Max Rate : 5 Gbps)
•8* DAC FMC2 Connector ( 14 bit, Max Rate : 9.855 Gbps)
•2* DDR4 clamshell Component 4X8 bit ( 4GB)
•1* SFP28
•PS
•1*DDR4 SODIMM (X64 Bit)
•1*USB 3.0 •1*SD Card 3.0/2.0
•1*Gigabit Ethernet
•1*UART
•2 * QSPI Flash (boot)
•CLK Source
•4* PL GTYP Ref-CLK (SFP28)
•2* PL DDR4 CLK (DDR4 Component)
•1* PS GTR CLK (USB3.0)
•3* PL CLK •1* OSC , PS Ref-CLK(33.333MHz)
•CLK Module for ADC/DAC (6 sets)
•BMC Control
•Voltage /Current Monitor
•Automatic shut-down upon detection of over-current, over-voltage or over-temperature
•Power Sequential Control
•CLK Frequency Setting
•Independent 5V Power Supply Control
•Jtag for Xilinx tool Download/Debug •TPS-UI Display and Peripheral Setting through USB2.0 to UART
Request Full Specifications:
Detailed datasheets and technical documentation are available upon request.
Please contact our team for more information regarding the TPS-ZU48DR RFSoC Platform .
